Original: $1,888.83
-70%$1,888.83
$566.65The Story
The SmartSolar MPPT RS 450/200 solar charge controller is Victron's solution for systems with large series connected PV arrays charging 48 V DC battery banks up to 11.52kW.
Victron has released an important safety update regarding the RS range of products, including MPPT RS charge controllers.
Please see the safety notes here for more information.
This product is perfect for large off-grid and grid connected battery systems.
Available in 5.76kW (450/100-MC4) and 11.52kW (450/200-MC4) models.
MPPT RS features include a wide 80-450 VDC operating solar voltage input, independent tracking inputs, full connectivity including Bluetooth, isolated PV connections, display screen, fully programmable battery charging parameters and active cooling.
The new metal case design and fully covered electrical connections improve the safety and modernise the presentation in line with the latest suite of Victron products.
NOTE: Genuine MC4 connectors must be used.
Ultra-fast Maximum Power Point Tracking (MPPT) with 4 Trackers on the 450/200 (2 on 450/100 model).
Especially in the case of a clouded sky, when light intensity is changing continuously, a fast MPPT algorithm will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions:
If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPT's tend to lock to a local MPP, which may not be the optimum MPP. The innovative SmartSolar algorithm will always maximize
energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency
Maximum efficiency of 96%. Full output current up to 40°C (104°F).
Fully programmable charge algorithm and eight preprogrammed battery presets.
The Charge Controller is configured for a three step charging process:
Bulk – Absorption – Float.
A regular equalization charge can also be programmed.
Optional external voltage and temperature sensor
Wired connections are available for battery voltage and temperature sensing.
The Solar Charger uses these measurements to optimise its charge parameters. The accuracy of the data it transmits will improve battery charging efficiency and prolong battery life.
Interfacing and Communications
Configure with the VictronConnect app. Available for iOS, Android devices, as well as macOS and Windows computers.
VE.Direct port and two VE.Can ports. Either communications port type can be used for a wired data connection to a GX device (e.g. Ekrano GX, Cerbo GX, Color Control GX), PC
or other devices.
(Note that only one port can be used at a time. VE.Direct to USB accessory is required for Windows systems; enter VictronConnect in the search box on our website and see the VictronConnect download page for details).
Remote on-off input and Programmable relay
Can be programmed (with a smartphone) to open or close on an alarm, or other events.
Device Display
A 4 line LCD back-lit display shows operational information including battery levels, solar yield, and system icons.
Specifications
Manual
Click here to view User Manual
Warranty:
Click Here To View The Victron Energy Limited Warranty Policy DOCUMENT
