Victron SmartSolar MPPT Charge Controllers
Connectivity & Control
Bluetooth Smart: Enables a wireless approach for easy setup, monitoring, updates, and synchronisation of your SmartSolar Charge Controller.
- VE.Direct: Provides a wired connection to devices like Color Control GX, PCs, and other GX products.
Efficiency & Harvesting
Ultra-Fast MPPT: When the sky gets cloudy and light intensity varies, this ultra-fast MPPT feature ensures up to 30% more energy harvest than PWM controllers and 10% more than its slower counterparts.
Load Management
Load Output: Safeguard your battery from over-discharging by linking all loads to the load output. If the battery's charge drops to a set voltage, the load disconnects automatically, ensuring battery health.
Battery Life Algorithm: Protects your battery from frequent cycling between partial and full discharges. It adjusts the load disconnect levels daily, ensuring your battery recharges close to 100% approximately once a week.
Temperature Management
Internal Temperature Sensor: Automatically adjusts charge voltage based on ambient temperature, ensuring optimised charging.
Optional External Sensors
Via Bluetooth, integrate with tools like Smart Battery Sense or BMV-712 Smart Battery Monitor for external battery voltage and temperature data.
Additional Features
Programmable Charge Algorithm: Customise your charging process. With a flexible charge algorithm, choose from eight pre-set modes or customise your own.
Battery Recovery: Capable of kick-starting charging even for a battery discharged to zero volts and can reconnect with fully drained Li-ion batteries.
Comprehensive Protection
The SmartSolar Charge Controller is built to last, featuring protection against high temperatures, PV short circuits, reverse polarity and reverse current.
There's also a temperature sensor to adjust charge voltage based on the environment.
Advanced Features:
- Synchronised Charging: Sync up to 10 units via Bluetooth for a unified charging system.
- Battery Recovery: Can jump-start batteries discharged to zero volts and even reconnect to fully discharged Li-ion batteries.
- Connectivity Options: Use VE.Direct for wired connections to various devices, and remotely switch the unit on or off with the VE.BUS BMS.
- Relay & Display Options: Comes with a programmable relay for alarms or other events. For those who prefer a physical interface, an optional pluggable LCD display can be attached.
Specifications
