Victron Multi RS Solar 2 Tracker Inverter/Charger 48/6000/100 -450/100 - PMR482602020

The Multi RS Solar 48/6000 is a 48V 6kVA Inverter/Charger with two independent 3kWp PV 450V MPPT tracker inputs for 6kWp PV total.

Thanks to high frequency technology and a new design this powerful inverter weighs only 11kg. In addition to this it has an excellent efficiency, low standby power, and a very quiet operation. The display reads battery, inverter and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth enabled device, using the VictronConnect app.

In mid-2023 the Multi RS was revised from a single MPPT tracker to a dual MPPT tracker model and now accepts a generator input.

Victron has released an important safety update regarding the RS range of products.
Please see the safety notes here for more information.

Customers Please Note:
The Victron RS inverter range has 3 models and can be a bit confusing; here is a breakdown of the models. Select the model for your particular application:

(This Model) Victron Multi RS Solar 2 Tracker Inverter/Charger 48/6000/100 -450/100 - PMR482602020:
Inbuilt 2 x MPPT Solar Charge Controller, all in one Solar Power solution.

Victron Inverter RS 48/6000 230V Smart Solar - PIN482601000:
Inbuilt 1 x MPPT Solar Charge Controller, all in one Solar Power Solution

Victron Inverter RS 48/6000 Smart Inverter only - PIN482600000:
No Solar Charge Controller, Inverter Only with Bluetooth Connectivity

Features:

Operating modes:

• Hybrid mode – Stores excess solar energy in a battery, to be used during the night or periods of high demand. Supplies additional power from the battery when demand exceeds grid capacity.

• Backup mode – Switches to backup mode during a grid outage.
• Off-grid mode – Operates without grid connection.
• Generator mode – Controls the generator to minimize run hours. Supplies additional power from the battery when demand exceeds the capacity of the generator.

PowerControl and PowerAssist - Boosting the capacity of the grid or a generator: A maximum grid or generator current can be set. The Multi RS will then take account of other AC loads and use whatever is extra for battery charging, thus preventing the generator or grid from being overloaded (PowerControl function). PowerAssist takes the principle of PowerControl to a further dimension. Where peak power is so often required only for a limited period, the Multi RS will compensate insufficient generator or grid power with power from the battery. When the load reduces, the spare power is used to recharge the battery.

Display, Bluetooth and VictronConnect app: The display reads battery, inverter and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth enabled device, using the VictronConnect app.

Extendable PV capacity, both AC-coupled and DC-coupled: The integrated 6 kWp PV capacity can be extended by adding solar chargers to the system. Alternatively, the PV capacity can be extended by installing PV Inverters, of which the output power will be automatically controlled by the integrated frequency shift power control.

Communication ports: VE.Can connection to a GX device for system monitoring, data logging, and remote firmware updates. VE.Direct connection to a GlobalLink 520 for remote data monitoring.

I/O Connections: Programmable relay, temperature sensor and voltage sensor connections.

Specifications:

Click Here to View Data Sheet

Manual

Click Here to view User Manual PDF

Warranty:

Click Here To View The Victron Energy Limited Warranty Policy DOCUMENT
